Running Mode Stationary 0.4-1.5 Ton Marco High Scissor Lift Table for Warehouse Crane

Large Image : Running Mode Stationary 0.4-1.5 Ton Marco High Scissor Lift Table for Warehouse Crane

Product Details:

Certification:	CE

Contact Now

Running Mode Stationary 0.4-1.5 Ton Marco High Scissor Lift Table for Warehouse Crane

Description

Model NO.:	E. G.: M0-004080-D12H	Feature:	Insulating
Transport Package:	Wooden Pallet	Specification:	CE
Trademark:	Marco	Origin:	Ningbo, China
HS Code:	8428909090	Application:	Workshop Crane, Shipboard Crane, Warehouse Crane, Building Crane
Lift Mechanism:	Scissor Lift	Carrying Capacity:	Weight Level
Moves:	Stationary	Driven Type:	Hydraulic
Running Mode:	Stationary	Customization:	Available \| Customized Request

Higher strokes are achieved by designing the lift table with a multiple set of vertically mounted scissors.

High-lift scissor lift table can be used for example as work platforms, pallet loaders, elevators, disabled persons lifts and pallet stackers.

If compared with a traditional elevator Marco high lift is a rational and cost saving solution.

Main Specification:
1.Standard Options

Pump: Europe brand
Control box- dead man control with up/down/E-stop

Cylinder: Marco designing, OEM made, including rupture valve, damping action and pilot valve

Sealing kit for cylinder: SKF brand

Motor: Hoyer motor, protection IP55

Scissor arm: Q345B

Hydraulic hose/fitting: Eaton

Paint: Finland brand - Tikkurila

2.Options extra:Depends on your require

Our Services:
1. For all your inquires about us , we will reply you in detail within 24 hours
2. We own well-tranied and passional sales and after- sale services who can speak fluent Engligh language
3. We can provide customise solutions to particular requirements
Packaging & Shipping:
Main Loading Port: ShangHai or Ningbo
Production Delivery: 6-8 weeks (public holiday excluded)

Hot sales for 0.4-1.5 Ton Marco high lift table with CE approved:

Art.No.	Type	Capacity ( kg)	Platform (L*W)	Lift Height (mm)	Own Height (mm)	Lift time (s)	Motor (kw)	Weight (kg)
860660	M0-004080-D12H	400	800*600	800	200	19	0.55	120
860105	M2-005180-D12H	500	1350*1000	1800	350	19	1.1	370
860102	M2-005320-D22H	500	2250*1000	3200	400	40	2.2	550
860110	M2-0010180-D22H	1000	1350*1000	1800	350	22	2.2	370
860114	M2-010200-D22H	1000	1500*1000	2000	350	22	2.2	400
860115	M2-010250-D22H	1000	1800*1000	2500	350	32	2.2	475
860118	M3-010320-D22H	1000	2250*1000	3200	500	47	2.2	770
860180	M2-010330-D23H	1000	1650*1000	3300	530	38	2.2	665
860111	M2-015180-D22H	1000	1350*1000	1800	400	22	2.2	375
